81
> Change from previous revision
TR330
Item Part No. Qty. Description Serial Numbers/Notes
1
N/S 1 Ball, Emergency Steering
2 N/S 1 Stop, Ball
3 N/S 1 Thin Bearing Race
4N/S1Bearing
5 N/S 1 Thick Bearing Race
6 N/S 1 Spool
7 N/S 1 Spring Retaining Ring
8N/S1Cross Pin
9N/S1Sleeve
10 N/S 1 Set, Spring
11 N/S 1 Check Valve, Ball
12 N/S 3 Screw, Special
13 N/S 5 O-Ring Included in seal kit
14 N/S 1 End Cover
15 N/S 2 O-Ring Included in seal kit
16 N/S 1 Rim, Gearwheel
17 N/S 1 Gearwheel
18 N/S 1 Distributor Plate
19 N/S 1 O-Ring Included in seal kit
20 N/S 1 Spacer
21 N/S 1 Cardan Shaft
22 N/S 1 Housing
23 N/S 1 Relief Valve
Adjust the Check Valve to 1500 psi
(103 BAR)
24 N/S 1 Spring, Relief Valve
25 N/S 1 Seal, Shaft Included in seal kit
26 339909 3 O-Ring, -6 ORFS
27 339908 2 O-Ring, -4 ORFS
28 N/S 3 Screw, Special
4197940 1 Seal Kit
