Page #87 background imageLoading...
Page #87 background image
87
> Change from previous revision
TR330
46 4 Screw
47 1 O-Ring Included in seal kit
48 1 Trunnion Cover
49 1 O-Ring Included in seal kit
50 4 Screw
51 1 Housing
52 2 Dowel Pin
53 1 Plug Assembly
54 1 • O-Ring Included in seal kit
55 2 Retaining Ring, External
56 1 Ball Bearing
57 1 Retaining Ring, Internal
58 1 Coupling, 9 Tooth
59 1 Shaft, Input
60 1 Seal, A-Flange
4169328 1 Seal Kit
Item Part No. Qty. Description Serial Numbers/Notes
