97
> Change from previous revision
TR320
Item Part No. Qty. Description Serial Numbers/Notes
1
685709 1 MOW Stop Plate
2 685760 1 Pedal
3 686372 1 MOW Lever Weldment
4 685764 1 Traction Lever Weldment
5 670806 1 Transmission Pedal Base Plate
6 3003474 1 Pedal Grip
7 3003475 1 Pedal Grip
8 4185740 2 Fitted Assembly
9 4200040 1 Detent Screw, M12
10 4377886 1 MOW Mode Bracket
11 128079 1 Rod End, 1/4”
12 691426 1 Panel Grip
13 450003 2 Hex Bolt, M6 - 1 x 40
14 450001 1 Hex Bolt, M6 - 1 x 30
15 450014 1 Hex Bolt, M8 - 1.25 x 30
16 450172 6 Hex Screw, M6 - 1 x 25
17 450192 4 Hex Screw, M6 - 1.25 x 25
18 450193 2 Hex Screw, M8 - 1.25 x 30
19 450194 1 Hex Screw, M8 - 1.25 x 35
20 450205 1 Hex Screw, M8 - 1.25 x 90
21 450324 2 Hex Nut, M8 - 1.25
22 450333 1 Hex Nut, M12 - 1.75
23 450377 3 Hex Nut, M6 - 1
24 450389 13 Washer, M6 x 12.5 x 1.8
25 450390 8 Washer, M8 x 17 x 1.8
26 452435 6 Hex Nut, M6
27 452436 7 Hex Nut, M8
28 450020231 1 Hex Nut, 1/4 - 28 Grade 1
29 689290 2 Pedal Packer Plate
30 4850325 1 Hex Nut, M10 - 1.5
31 450215 1 Hex Screw, M10 - 1.5 x 30
