99
> Change from previous revision
TR320
Item Part No. Qty. Description Serial Numbers/Notes
1
4169021 1 Weight Transfer And Lift Valve
2 4273470 8 AV Washer, 13 x 19.5 x 2.5
3 679012 1 Weldment
4 679240 2 Standard Unit Mounting Bracket
5 MBE3454 2 Spacer, 10.5 x 20 x 13
6 450028 2 Hex Bolt, M8 - 1.25 x 110
7 450243 16 Hex Screw, M12 - 1.75 x 40
8 450326 4 Hex Nut, M12 - 1.75
9 450378 2 Hex Nut, M8 - 1.75
10 450402 12 Washer, M12 x 28 x 2.7
11 450411 2 Lock Washer, M8 x 12.75 x 2
12 452438 12 Hex Nut, M12
13 002449048 1 Test Point, 1/8 BSPP x M16
14 339909 1 O-Ring, .364 ID
15 340061 1 Elbow, 90 Deg 6-6 Straight Thread
16 340062 1 Elbow, 90 Deg 6-8 Straight Thread
17 340097 1 Tee, Branch
18 340119 1 Tee, Swivel Run
19 4186000 1 Cross, M/M/M/F 11/16 ORS
20 4287314 1 Orifice Disk, .070 Dia
21 4294715-04 1 Fitting, 90 M/M 11/16” ORS x 9/16”
22 69068-03 1 Orifice Disk, .06 x .028 Dia
23 69068-04 2 Orifice Disk, .06 x 0.33 Dia
