CONTROLS 6
en-20
6.2 CONTROL PANEL _________________________________________________________
6.2.1 IGNITION SWITCH _________________________________________________________
The ignition switch has three positions, OFF, RUN and START.
6.2.2 PTO SWITCH _____________________________________________________________
The PTO switch is a 2-position knob type switch to engage and to disengage the cutting unit. The
PTO switch must be in the OFF (down) position to start the engine.
Pull on the red knob to move the switch to the ON position. When the PTO switch is in the ON
position, the cutting unit is engaged.
Always mow with the throttle lever in the fast position.
STOP
CHOKE
6.2.1
6.2.2
6.2.4
6.2.5
HR
6.2.3
STOP
OFF
RUN
START
