29
serial nameplate
To register your spa you need to have your spa serial number. The
best time to retrieve the serial number is when the spa is being con-
nected. You must register your spa via the internet at www.Jacuzzi.
com.
Follow these steps to register your spa.
1. Using your home computer or other device, connect to the
internet.
2. Go to www.Jacuzzi.com website to register your spa.
3. Click Outdoor Hot Tubs
4. Click For Owners
5. Click Warranty and Manuals
6. Click Warranty Registration
7. Enter your serial number.
8. Once registered you will be given a passcode that will need to
be entered into the control panel.
Keep a record of your serial number and passcode for any future
reference. Write that information below.
Serial Number: _ _ _ _ _ _ _ _ _
Passcode: _ _ _ _ _ _ _ _ _
Completing Your Registration
Once the spa is registered online, you will continue the process
at the spa control panel. You will need to enter the serial num-
ber and passcode given when you registered online. Follow the
steps below.
Note: The control panel does not have a back button. If an incor-
rect number is entered you must complete the entire registra-
tion steps. At that point, the system will return an “INCORRECT
PASSCODE” message.
A. Entering the Serial Number and Passcode
1. Press ( ) until you get to the “S\N” Menu. The display will
scroll “SET SERIAL NUMBER.”
Note: Once a valid serial number and passcode have been ente-
red, this screen will not appear again.
2. Press (
) to prepare the system.
3. Enter the serial number. Using the or buttons you can
cycle through the numbers 0 to 9.
4. Once you reach a desired number release the button. Press (
) after selecting each of the numbers and allow the cursor to
move to the next selection. After the last number is saved, pro-
ceed to enter the passcode.
6. Using or you can cycle through the numbers 0 to 9.
7. Once you reach a desired number release the button. Press (
) after selecting each of the numbers and allow the cursor to
move to the next selection.
8. If the passcode is correct, the display will scroll “PASSCODE
ACCEPTED.” If there was error, the display will scroll “INCORRECT
PASSCODE.” You will need to re-enter the passcode.
Setting water temperature
Press (or press and hold) either (
or ) to adjust the current
temperature setting. Once the desired temperature is reached,
do not press any buttons on the control panel for about 3 se-
conds. The new temperature setting will saved. When the spa is
heating the heat icon ( ) will be displayed.
To access the overtemp feature that allows the spa to reach 41°C
(106°F) continue to the next steps.
1. Press and hold (
) then;
2. Press and hold the (
) at the same time for 2 seconds. You
will see the temperature change to 105°F (40.5°C) on the LCD
display. Press ( ) to raise the temperature to 106°F (41°C) To
lower the temperature, press ( .).
3. When the overtemp has been activated, the asterisk after the
last digit will appear as an indicator for being in the overtemp
mode.
Note: Once the temperature goes below 40°C (104°F) and you
would like to raise the temperature to 41°C (106°F) again, you
will have to repeat the steps.
Activate Jet Pumps
1
2
The JETS 1 (
) button activates jets pump 1. The rst press
turns jets pump 1 on; the second press turns jets pump 1 o. The
JETS 2 (
) button activates jets pump 2 (if equipped). The rst
press turns jets pump 2 on; the second press turns jets pump
2 o. When manually activated, either pump will automatically
turn o after 20 minutes.
Light On/O Button
Pressing this button activates the waterfall light, footwell light,
lighted cup holders, and backlit pillows lights in unison as fol-
lows: high - medium - low - o.
Note: Lights automatically turn o after 2 hours
Light Mode Button
This button oers 4 light modes for your enjoyment. Press this
button to select your favorite lighting eect as follows:
Press once
High-Speed Colour Blend Mode.
Press again
Low-Speed Colour Blend Mode.
Press again
Freeze Colour Blend Mode:
Selects or “freezes” your low speed blending colour of choice.
