1. Locate the door’s retractable push button on the top of the
front panel (1).
2. Press the retractable push button to release the panel door
from the spa frame (2).
3. Slowly and gently tilt the panel forward to remove (3). This
will expose the equipment bay for easy access to the compo-
nents. Place the panel in a safe location to prevent from dama-
ging it.
4. To reinstall the panel just follow the steps above in reverse
order.
Maintaining The Synthetic Cabinet
Your new spa’s synthetic cabinet requires little or no maintenan-
ce of any kind. To clean, simply wipe cabinet with a clean towel
and mild soap solution.
ATTENTION: Never spray cabinet with a garden hose for any
reason since this action may induce an electrical short in the
spa’s electrical equipment.
Winterizing
Your Jacuzzi spa is designed to automatically protect itself
against freezing when operating properly.
During periods of severe freezing temperatures, you should
check periodically to be certain that the electrical supply to the
spa has not been interrupted.
In extreme bitter cold weather, less than 0°C (32°F), program
the primary ltration cycle to run for 24 hours to prevent
freezing
If you do not intend to use your spa, or if there is a prolonged
power outage during periods of severe freezing temperatures,
it is important that all water be removed from the spa and
equipment to protect against damage from freezing.
Expert winterization of your spa is highly recommended,
contact your authorized Jacuzzi dealer. In emergency situa-
tions, damage can be minimized by taking the following steps:
1. Turn o power to the spa.
2. Follow the directions for draining the spa.
3. Turn the massage/diverter selector(s) into the middle combo
position to allow the water in the plumbing lines to drain.
4. Turn the waterfall valve(s) to the open position to allow the
water in the plumbing lines to drain.
5. Open all the air controls and leave them open until you resu-
me use of the spa.
6. As the water level drops below the seats, use whatever means
necessary to get the water out of the recessed seating areas and
into the footwell, such as a wet/dry vacuum.
7. When the water level ceases to drop, use whatever means
available to remove any remaining water from the foot well,
such as a wet/dry vacuum.
8. Remove the synthetic cabinet panel under the control panel
and locate the drain plugs on the front of the pump(s). Remove
plugs to allow water to drain out of pumps and heater.
Note: Use a wet/dry vacuum or other means to keep this from
ooding the equipment compartment. Replace the drain plugs.
9. Loosen the hose clamp on the circulation pump intake behind
the control box and pull the hose o (twist hose back and forth
while pulling outward). Tip hose down and allow to drain, then
reinstall hose and clamp.
10. Loosen hose clamp at bottom of CLEARRAY® system and
pull hose o of CLEARRAY® tting (twist the hose back and for-
th while pulling downward). Tip hose down and allow to drain.
Then reinstall hose and clamp. Remove the cover of the CLEAR-
RAY® system to access the UV bulb and quartz tube. Remove
and store the UV bulb in a safe location. Remove and dry o the
quartz tube then reinstall it. Depending on the length of time,
consider replacing the UV bulb when you resume use of your
hot tub.
11. Reinstall synthetic cabinet side panel and cover spa so that
no casual moisture can enter into it.
Restarting Your Spa in Cold Weather
If you want to start up your spa after it has sat empty for a time
in freezing temperatures, be aware that the water remaining in
certain sections of the piping may still be frozen. This situation
will block water ow preventing the spa from operating proper-
ly and possibly damaging the equipment.
We recommend you consult your authorized Jacuzzi dealer for gui-
dance before attempting to restart your spa under these conditions.
CLEARRAY® (Ultraviolet) Water Purication System
CLEARRAY® Water Purication System is exclusive
technology utilizing natural ultraviolet technology to elimi-
nate waterborne bacteria, viruses, and algae in portable spas.
The ultraviolet light otherwise known as UV-C or germicidal li-
ght inactivates the microorganisms disrupting the DNA so that
it cannot reproduce and is considered lifeless. CLEARRAY® is
plumbed in-line with your ltration system. After the water is
drawn from the pump, lter, and heater it is then directed thou-
gh the CLEARRAY® system. Water passes through an ultraviolet
light energy that treats and disinfects the water. The water is
then pumped back into the spa giving you crystal clear water
instantly. The system has a ballast that is the power supply for
the purication system; it has two LED indicator lights the green
indicating incoming power ow and the red indicating the sy-
stem is properly working. CLEARRAY® is standard for all models.
