Jacuzzi J-300 Series Installation Manual And Use & Maintenance

67
Collegamento bifase 50 Hz • Dual Service 50Hz Connection • Connexion Biphasée à 50 Hz
Collegamento monofase 50Hz • Single Service 50Hz Connection • Connexion Monophasée à 50 Hz
Deve essere installato il filo bianco supplementare incluso (1*) • The included extra White wire (1*) must be installed • En outre, le fil blanc supplémentaire fourni
(1*) doit être installé
1
2
3
GRN
N2 BLU
L1 BRN
N1 BLU
L2 BRN
A
B
C
D
P1 2SPD
UV
A/V
30A (PMP 1)
30A (PMP 2)
J33
J36
J53
J41
J46
J47
J51
J59
J38
J44
J49
F4
F6
J35
J37
G-GRN
L1 BRN
N1 BLU
A
B
C
D
P1 2SPD
UV
A/V
30A (PMP 1)
30A (PMP 2)
J33
J36 J53
J41
J46
J47
J51
J59
J38
J44
J49
F4
F6
J35
J37
1*
2
4
3
ALL MODELS
Two Service Jumper Wiring
Wire From To
1 J33 J51
2 J59 J38
3 J37 J53
ALL MODELS
Single Service Jumper Wiring
Wire From To
1* J33 J47
2 J59 J41
3 J37 J36
4 J46 J51
*Extra connection must be
made
COLLEGAMENTO MORSETTIERA·BREAKER TERMINAL CONNECTIONS · BRANCHEMENT BORNIER ANSCHLUSS KLEMMENLEISTE ·
CONEXIÓN BORNERA · ПОДСОЕДИНЕНИЯ КЛЕММНОЙ КОЛОДКИ
L1 = Riscaldatore • Heater • Chauffe-eau
L2 = Tutti gli altri componenti • All other components • Tous autres composants
COLLEGAMENTO MORSETTIERA·BREAKER TERMINAL CONNECTIONS  BRANCHEMENT BORNIER
L1 = Tutti i componenti • All components • Tous les composants
Impostazioni di fabbrica
Factory setting
Congurations faites en usine

Jacuzzi J-300 Series Specifications

General

Series	J-300 Series
Shell Material	Acrylic
Dimensions	84" x 84" x 36"
Water Capacity	350 gallons
Pumps	2
Lighting	LED lighting
Water Management	ClearRay Active Oxygen System
