Jacuzzi J-400 Series

Page 29
J-400 Series
9.8 J-465 Massage/Waterfall Selector Diagram
Massage Selectors (1)
• Massageselector1divertsoutputbetweenjetsgroups1a-1b.
Mass Aspiration Jet Flow Control Valve (2)
• Valve2controlsoutputtofootwellIXJet.
Waterfall Selector (3)
• Waterfallselector3controlscirculationpumpoutputtowaterfall.
Jets Without Massage Selector Controls (4)
• Jets4arealwaysonwhenjetspumpisrunning.
