62
Tilt PowerPro MX2 Jet nozzle to angle of choice as desired. Ro-
tate nozzle clockwise to reduce flow volume from jet or rotate
counterclockwise to increase flow volume.
Note: Always keep at least 6 adjustable jets open at all times.
Adjusting RX Jets
Rotate the outside jet face clockwise to decrease or shut off water
flow. Turn counterclockwise to turn on or increase water flow.
Note: Always keep at least 6 adjustable jets open at all times.
WaterColour™ Waterfall Control
Turn waterfall control valve counterclockwise to increase wa-
terfall output. Turn control valve clockwise to decrease or turn
off waterfalls.
Note: When the waterfall is in the OFF position, some water may
still flow through. This is considered normal.
Air Controls
Certain jet systems have their own air controls. Each control
injects air into the water lines that supply that specific jet group.
Press one side of the air control to open and the opposite end
to close.
Note: Certain jets may draw air even though they are closed. This
is considered normal.
Selecting the Desired Massage Action
B
C
A
Your Jacuzzi spa is equipped to allow you to custom-
ize the massage action you desire. Each model incorporates a
massage selector that allows you to customize the massage
and performance by diverting water between various jet sys-
tems. Simply turn the massage selector to position A (Combo),
B, or C to divert water pressure to various jet groups.
Note: The massage selector valve(s) is designed to operate in
positions A(Combo), B, and C for optimum performance. It is con-
sidered normal for sound levels within the valve to vary between
positions due to the large amounts of water flowing through it.
For optimum filtration benefits, leave the valve in the center posi-
tion when the spa is covered. Select position B or C for maximum
jet performance during spa use.
Indicator Light
The indicator light located on the front cabinet panel of the spa
is an early detection system that will notify you when the spa
needs immediate attention. A solid white light indicates that
all operations are normal. A solid red light indicates that im-
mediate attention is required to clear or fix an error code. For a
detailed explanation see section titled “Error messages”.
External lights (optional)
The external lights on the hot tub light up the area around it.
These lights can be activated from the “Lights” menu (the only
available colour is white). Once active, they remain on for 8
hours (they can be turned off as desired).
SmartTub™ system (optional)
This control system allows you to check the operating status of
your hot tub on your mobile device, making it easier to manage
and maintain. Any messages relating to possible hot tub mal-
functions will be shown on the screen on your device.
Note: the service is free for the first year; at the end of that period,
if you want to continue to use the functions of the SmartTub™
system, you must renew your subscription (for further information,
refer to the terms and conditions of use by clicking on the relative
links in the app).
Note on the processing of personal data: the creation of
an account and relative registration of the hot tub (necessary to
use the SmartTub™ system) entails Jacuzzi collecting some data,
such as the serial number of the product, the name, surname and
address of the person registering the hot tub, and also their email
address. If any online purchases are made of offers on the app,
payment details will also be collected.
The information collected allows the app to provide the services
required, such as enabling remote control of water temperature,
monitoring consumption or indicating when the Clearray® bulb or
the filter cartridge needs to be replaced.
If a particular part should break, the app lets you contact your
preferred dealer via email or by phone, so that they can access the
error messages and then provide effective help in pinpointing the
cause of the fault.
For any questions regarding the processing of personal data and
the relative regulations on privacy, please visit our website: www.
jacuzzismarttub.com
QRegistration
- First of all, download the SmartTub™ app from the Google Play
store or the Apple store.
- Launch the app: to create an account, select “sign up” and
enter your email address, a password and the serial number
of your hot tub (found under the QR code, next to the control
panel); you can also use the QR reader incorporated in the
app to read the hot tub’s QR code.
Note: you can agree to or decline the option to receive informa-
tion about the use and maintenance of the hot tub that is sugge-
sted by the app; alternatively, you can also go to: Jacuzzi.app@
