EXPLODED VIEW OF J-SHOWER TOWER
END CAP
SEE PAGE 20
BOTTOM RAIL
SEE PAGE 15 & 16
SET SCREW
SEE PAGE 16
PINS
SEE PAGE 11
FACEPLATE
SEE PAGE 21
MIXER/DIVERTER
(INCLUDING HOSE
CONNECTIONS)
SEE PAGES 10 & 11
FILL SPOUT
SEE PAGE 8
