Shower Tower Hardware
Identification Chart
The diagrams for these fasteners are shown actual size for fast identification.
HARDWARE
SCREW COVER
COVER
QTY.-6
H10
SET SCREW
#8-32 x 1 1/2"
SCREW
QTY.-1
H17
LOWER TRACK
END CAP
CAP
QTY. -1
H16
EXTERNAL TOOTH
LOCK-WASHER #8
STAINLESS STEEL
WASHER
QTY.-4
H15
SHEET METAL
SCREW
#8-18X 2" S.S.
SCREW
QTY.-1
H14
PAN HEAD
PHILLIPS
#8-32 x 3"
SCREW
QTY.-3
H13
SHEET METAL
SCREW
#10-16X 2" S.S.
SCREW
QTY.-2
H12
FLAT WASHER
#10 TYPE A
STAINLESS STEEL
WASHER
QTY.-2
H11
PIN #8-32
.25DIA X 1"
PIN
QTY.-3
H4
PAN HEAD SCREW
#8-32 x 1/2"
STAINLESS STEEL
SCREW
QTY.-3
H6
FLAT WASHER
#8 TYPE B
STAINLESS STEEL
WASHER
QTY.-10
H5
HEX LOCKNUT #8-32
NUT
QTY.-1
H7
M4.2X19MM
STAINLESS STEEL
SCREW
QTY.-7
H8
M3.5X9.5MM
STAINLESS STEEL
SCREW
QTY.-11
H9
NUT
QTY.-8
HEX NUT
10 x 32
H2
H1
BOLT
QTY.-8
SLOT
FASTENER
10 X32
WASHER
QTY.-8
EXTERNAL TOOTH
LOCK-WASHER #10
STAINLESS STEEL
WB3
SCREW
QTY.-8
H3
SET SCREW
6 x 32
