6
Shower Tower Hardware
Identification Chart
PLUMBING HARDWARE
The diagrams for these fasteners are shown actual size for fast identification.
FIBER WASHER .75 O.D.
WASHER
QTY.-2
SCREW
QTY.-6
PHILLIPS HEAD
SCREW M4X12
STAINLESS STEEL
P3
WASHER
QTY.-3
EXTERNAL TOOTH
LOCK WASHER M4
WASHER
QTY.-6
NIPPLE
QTY.-1
LOCKNUT
QTY.-1
COMPRESSION
RING
QTY.-1
GASKET
QTY.-1
GASKET
QTY.-1
FOAM GASKET 3" O.D.
FOAM GASKET
1" O.D.
MIXER HARDWARE
RUBBER
WASHER
1.75 DIA
STANDOFF
QTY.-3
P7
P2
P1
P5
P6
P8
M1
M2
P4
