A2 Checking Current Consumption of Devices
This table lists current draw for most major hot tub components:
2011-2013 J300 Collection
(North American 60 Hz)
Device
Current
Consumption ±10%
Pump 1 (2-speed) High/
Low 9.5A-12.0A/2.6A-3.6A
Pump 1 (2-speed) High/
Low (J-315/J-325 only) 10.6A-13.6A/2.6A-3.9A
Pump 2 (High speed only) 9.0A-11.0A
Heater 1 kW/4 kW (Con-
vertible Models Only)
7.0A-9.0A (120 VAC)
16.7A (240 VAC)
Heater 5.5 kW 19.5A-23.5A (240 VAC)
Circulation Pump 0.5A-1.0A
CLEARRAY (Standard) 0.4A
Ozone Generator (Opt) 0.1A
J-200 Collection
(North American 60 Hz)
Device
Current
Consumption ±10%
Pump 1 (2-speed) High/
Low 9.5A-12.0A/2.6A-3.6A
Pump 1 (2-speed) High/
Low (J-210 only) 10.6A-13.6A/2.6A-3.9A
Pump 2 (High speed only) 9.0A-11.0A
Heater 1 kW/4 kW (Con-
vertible Models Only)
7.0A-9.0A (120 VAC)
16.7A (240 VAC)
Heater 5.5 kW 19.5A-23.5A (240 VAC)
Circulation Pump (Optional
for J-230, J-270 J-280) 0.5A-1.0A
CLEARRAY (Standard) 0.4A
Ozone Generator
(Optional) 0.1A
J-LX Collection
(North American 60 Hz)
Device
Current
Consumption ±10%
Pump 1 (2-speed) High/
Low 9.5A-12.0A/2.6A-3.6A
Pump 2 (High speed only) 9.0A-11.0A
Heater 5.5 kW 19.5A-23.5A (240 VAC)
Circulation Pump 0.5A-1.0A
CLEARRAY (Standard) 0.4A
Ozone Generator (Opt) 0.1A
J-LX/2011-2013 J300/J200 Models
(Export 50 Hz)
Device
Current
Consumption ±10%
Pump 1 (2-speed) High/
Low 6.3A-8.7A/2.2A-2.8A
Pump 2 (High speed only -
for 2-pump models) 6.3A-8.7A
Heater 2.7 kW 9.5A-12.5A (230 VAC)
Circulation Pump 0.3A-0.7A
CLEARRAY (Standard) 0.4A
Ozone Generator (stan-
dard) 0.1A
