J&M TF2 - Light Harness; Wing Prop

19
1
3
4
5
2
Description Part No.
1 Main A-Frame Wiring Harness with 7 Prong Connector End (Torsion-Flex) JM0027077
2 Light Enhancer and Adapter Kit (3 Wires) JM0010566
3 Light Wiring Harness (Torsion-Flex) JM0027080
4 Amber Light (Soil Conditioner, NitroGro) JM0009975
5 Red Light (Soil Conditioner, NitroGro) JM0009976
Light Harness
Description Part No.
1 Adjustable Prop - Platform (8” Long Tube) JM0044535
2 1/2”-13 x 3” Gr5 Z Hex Bolt JM0016678
3 Adjustable Prop - Upright (31” Long Tube) JM0044536
4 1/2”-13 x 4-1/8” x 5” Square U-Bolt JM0010001
5 1/2”-13 Gr2 Z Centerlock Hex Nut JM0001511
*Wing Prop only for TF212 & 215 with 13” basketes and
harrow bars.
Wing Prop
4
5
3
2
1
