J&M TF2 - Page 21

21
A-Frame Assembly
Description Part No.
1 Inner Tongue Weldment (TF2, TF212, TF215) JM0026437
2 1” x 8” Tongue Pin and Cotter Pin (18PCP) JM0027117
3 A-Frame Tongue Weldment (TF212) JM0026439
3 A-Frame Tongue Weldment (TF215) JM0026444
4 1-1/4”-7 Gr2 Z Nylon Locking Hex Nut JM0026789
5 1-1/4”-7 x 6” Gr5 Z Hex Bolt JM0016690
6 Hair Pin Clip For TF Hitch Pin JM0028344
7 1/2” Hose Holder Rod for TF Soil Conditioner, NitroGro (12HHR) JM0027120
8 3/8”-16 x 3/4” Gr5 Z Hex Bolt JM0001663
9 Turn Buckle Clevis End 1-1/4”-12 THD (1” Pin Hole) JM0026759
10 TF Turn Buckle Shaft - Both Ends R/H Thread (TBS-2RH) JM0026755
11 1-1/4”-12 Gr5 PN RH Hex Nut JM0019930
12 TF Turn Buckle Center Pipe Weldment (TBCB-1) JM0026758
13 1-1/4”-12 Gr5 PN LH Hex Nut JM0019931
14 Turn Buckle Shaft 1 L/H, 1 R/H (Gold Plated) (TBS-1RH1LH) JM0026757
15 1” x 3-1/2” Clevis Pin with Cotter Pins JM0026784
16 5/32” x 1-1/2” Cotter Pin JM0014348
17 3/8”-16 x 1/2” Hex Head Set Screw JM0019044
18 Operator’s Manual Canister JM0010115
19 1/4”-20 x 1” Gr5 Z SF Hex Bolt JM0001643
20 1/4”-20 Gr5 Z SF Hex Nut JM0001630
21 Wrench (TF) JM0015256
22 3/4”-10 x 6” Gr8 Z Hex Bolt JM0037185
23 CTD Perfect Hitch Clevis 1-1/4” x 1-3/4” Slot JM0037173
24 3/4”-10 Gr2 Z Centerlock Hex Nut JM0002147
25 CTD Perfect Hitch Base PP23XLR JM0037174
26 TF Telescoping Tongue Weldment for Gooseneck JM0044199
27 TF212 Gooseneck Tongue Weldment JM0044246
27 TF215 Gooseneck Tongue Weldment JM0044206
28 CTD Perfect Hitch Assembly (NitroGro) (Includes Bolt & Nut) JM0037177
