Dimmer Operation 10
Revision 2.0c – 30 August 2013 HPC User Manual
First
Level
Second
Level
Third
Level
Description
Use channel select buttons drive channel/s to full
When ON the N-E fault detector is enabled
Set the HPC to hold the current output upon loss
Set the HPC to fade to Scene 1 upon loss of DMX
Toggle the DMX terminate function. The TERM LED
indicates when the terminate function is active.
Level and RDM via DMX connector
Level via DMX connector and RDM via Ethernet
Level via Ethernet connector and RDM via DMX
Level and RDM via Ethernet connector
Cap the maximum output voltage. 240 = 240V
Some channels have Bypass enabled and some
Relay bypass will automatically activate
Relay bypass will not automatically activate
Some channels have Isolate enabled and some
Relay Isolate will automatically activate
Relay Isolate will not automatically activate
Display the internal measured temperature in
Display the DMX packet rate (per second)
Display the number of connected phases. Note
that 2.PH is displayed when 1 or 2 phase power is
Display the mains frequency
Press MENU/ to play Scene 1. Press and hold
MENU/ to record Scene 1.
to play Scene 2. Press and hold
MENU/ to record Scene 2.
Activate the chase and set the rate
Drive all channels in 10% increments
Table 2: Menu Function Reference
