Technical Data and Specifications 18
Revision 2.0c – 30 August 2013 HPC User Manual
9.0 Technical Data and Specifications
PARAMETER SPECIFICATION
Active-Neutral Supply Voltage
100-230VAC ±10% Full size neutral required
Supply Frequency 40-66Hz
Supply Protection 10K Amps
Rated Insulation Voltage 430VAC Phase to Phase, 250VAC Phase to Neutral
Rated Output Current 10 Amps per channel
Minimum Power/Channel 25W
Maximum Dissipation <24 W/channel
Electric Shock protection SELV
System Earth Type MEN
Output Protection Thermal/magnetic circuit breakers
Maximum Ambient Temperature 40ºC
Maximum Altitude 2000m
Over-temperature cutout Soft limit starts at 92°C, Full cutout at 100°C
Control Signal
ANSI E1.11:2004 DMX-512-A
ANSI E1.20:2006 RDM
DMX Input 5 pin AXR male / female
Snapshot Scenes 2
Test Function Level Individual Channels @ 100%
All Channels @ 10% steps
LED Indicators SIGNAL, ERROR, TERM, IC
Phases A, B, and C
Ingress protection IP20
Internal Separation Form 1
Environment B
Size 478mm (w) x 133mm (h) x 355mm (d)
Weight 19.5kg with 220us risetime
Rack mounting requirements Three x 19” rack spaces / standard spacing for mounting holes.
Inlet air ventilation on right side, exhaust air on left side (when
looking from front of unit). Rack must include suitable ventilation.
Power inlet at rear right.
