Jands HPC AIRGAP User Manual

Technical Data and Specifications 21
Revision 2.0c – 30 August 2013 HPC User Manual
9.2.2 Sub Device PIDs
One sub device per HPC channel (12 total)
Get Set PID Notes

SUPPORTED_PARAMETERS
 DEVICE_MODEL_DESCRIPTION Up to firmware rev 2.12:
Channel dependant
From firmware rev 2.13:
Same for all sub-devices
 MANUFACTURER_LABEL Same as root
  DEVICE_LABEL Up to firmware rev 2.12:
Not supported
From firmware rev 2.13:
Same as root and channel offset info

DEVICE_INFO
 SOFTWARE_VERSION_LABEL Same as root
  DMX_PERSONALITY 7 personalities to controls dimmer channel
mode (see user manual for details):
1 = Off
2 = On
3 = Dmx Switch
4 = Dimmer: Relay Control FULL
5 = Dimmer: Relay Control BYPASS
6 = Dimmer: Relay Control ISOLATE
7 = Dimmer: Relay Control NONE
 DMX_PERSONALITY_DESCRIPTION Off, On, Dimmer, Switch
  JANDS_HPC_PREHEAT_LEVEL Pid=0x8086, Pdl=0x1,
0x0=Off,
0x1=0x32 = Level for sub-device./ channel
  JANDS_HPC_OUTPUT_CAP_VALUE Pid=0x8088, PDL=0x1,
Up to firmware rev 2.00:
0x0=100%, (no output cap limit) 0x1-0xC = -5%
/ Step
From firmware rev 2.10:
0x00 = Full = 240V
0x1--0xE = -10V/ Step down to 100V
Global output cap limit for all channels (will
override any separate channel values)
Get will return 0xff if levels differ between
channels. (Also see sub-device PIDs)
