Jands HPC AIRGAP User Manual

Technical Data and Specifications 19
Revision 2.0c – 30 August 2013 HPC User Manual
9.1 DMX Connector Pinouts
PIN
No
CONNECTION
(DMX IN)
CONNECTION
(LOOP)
1 SHIELD SHIELD
2 IN- OUT-
3 IN+ OUT+
4 DMX Loop pin 4 DMX In pin 4
5 DMX Loop pin 5 DMX In pin 5
9.2 RDM Implementation
9.2.1 Root Device PIDs
Get Set PID Notes
- - DISC_UNIQUE_BRANCH
 DISC_MUTE
 DISC_UN_MUTE
  DEVICE_LABEL
 STATUS_MESSAGES Supported:
STS_OVERTEMP
STS_PHASE_ERROR
STS_DIM_PANIC
STS_JANDS_NEUTRAL_EARTH_FAULT (0x8000)
 STATUS_ID_DESCRIPTION For:
STD_JANDS_NEUTRAL_EARTH_FAULT (0x8000)
  QUEUED_MESSAGE
 SUPPORTED_PARAMETERS
 PARAMETER_DESCRIPTION
  DEVICE_LABEL
 DEVICE_INFO
 DEVICE_MODEL_DESCRIPTION
 MANUFACTURER_LABEL
  FACTORY_DEFAULTS Will always report 0 on Get
 SOFTWARE_VERSION_LABEL
  DMX_START_ADDRESS
 SLOT_INFO 1 per channel: ST_PRIMARY, SD_INTENSITY
 SLOT_DESCRIPTION “Chn-xx”
