JW-H67M-USB3 User's Manual
This is CPU conguration options, and show processor working states, such as frequency
，
64-bit support, maximum/min frequency, stepping, microcode version, code number and
hyper-threading technology support, etc.
• Hyper-threading
Setting hyper-threading technology open or closed
，
optional for Enalbed, Disbaled.
• Active Processor
Setting processor core number
,
optional for All
、
1
、
2
、
3
。
• Limit CPUID Maxinum
Set limits maximum CPUID
，
optional for Enalbed, Disbaled.
• Execute Disble Bit
Setting bits operation
，
optional for Enalbed, Disbaled.
• Hardware Prefetcher
Setting L2 Cache
，
optional for Enalbed, Disbaled.
• Adjacent Cache Line Prefetch
Setting to turn of/off prefectching of adjcent cache lines
，
optional for Enalbed, Disbaled.
• Intel VT
Optional for Enalbed, Disbaled.
• CPU C3 Report
Setting CPU C3(ACPI C2) report to OS
，
optional for Disbaled
、
ACPI C-2
、
ACPI C-3.
• CPU C6 Report
Setting CPU C6(ACPI C3) report to OS
，
optional for Enalbed, Disbaled.
• Package C State limit
Setting of CPU C energy-saving depth
，
optional for C0
、
C1
、
C6
、
C7
、
No Limit .
• Local x2APIC
Optional for Enalbed, Disbaled.

Press < ESC> key to return to the Advanced menu
►

Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Advanced
SATA Configuration
SATA Mode [IDE Mode]
(1) IDE Mode. (2)
AHCI Mode. (3) RAID
Mode.
→ ←
: Select Scree
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Serial-ATA Controler 0
Serial-ATA Controler 1
SATA1 Port A
SATA1 Port B
SATA2 Port A
SATA2 Port B
SATA3 Port A
SATA3 Port B
[Compatible]
[Enhanced]
ST380215AS (80.0G)
PIONEER DVD-RO ATAPI
Not Present
Not Present
Not Present
Not Present
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
