JW-H67M-USB3 User's Manual
• Power on by keyboard
When setting "Password Key specic", system can wake up with Password. When setting
"Any Key specic", system can wake up with any key of keyboard. When setting
"Disabled",system can't allow wake up with Keyboard.
Note: if you set the password boot functions, the mainboard boot button will failure
.
• Power on by Mouse
Set the mouse boot function
，
optional for Disabled
，
Enabled.
• AC Loss Back
Setting the system state choice after powre failure. Setting "Always Off", need to press case
panel on the Power switch to boot. Setting "Always On", the supply reply directly boot.
Setting "Keep last state", Power reply recovery system State before power off.
The default value as "Always Off".
Press < ESC> key to return to the Advanced menu
4.5.5 Chipset
Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Main Advanced Chipset Boot Security Save & Exit OC Drive
Audio Configuration Enable/Disabe Azalia
HD Audio.
Azalia HD Audio
Onboard PCI Device
Onboard Lan Controller
Onboard Usb3.0 Controller
►
USB2.0 Ports Control
►
Serial Port configuration
[Enabled]
[Auto]
[Auto]
[Auto]
→ ←
: Select Scree
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
Note:
Don’t forget your password. If you forget the password, you will have to
open the computer case and clear all information in the CMOS before you can start
up the system. But by doing this, you will have to reset all previously set options.
• Azalia HD Audio
Setting Azalia hd audio functions
，
optional for Disabled
，
Enabled.
• Onboard PCI Device
Setting chipset high-speed PCI interface functions, optional for Disabled
，
Enabled
，
Auto
.
• Onboard Mini PCIE
Setting chipset high-speed Mini PCI interface functions,optional for Disabled
，
Enabled
，
Auto
.
