J&W JW-H67M-USB3 User Manual

- 19 -
JW-H67M-USB3 User's Manual
Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Main Advanced Chipset Boot Security Save & Exit OC Drive
Legacy OpROM Support Enable or Disabe Boot
O p t i o n f o r L e g a c y
Network Devices.
Launch PXE OpROM
Launch Storage OpROM
►
ACPI Settings
►
RTC Wake Configuration
►
CPU configuration
►
SATA Configuration
►
USB Configuration
[Disabled]
[Enabled]
►
System Status Monitor
►
Advace Power Manage
→ ←
: Select Scree
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
4.5.4 Advanced
• Launch PXE OpROM
Setting PXE ROM open and close, optional for Enalbed, Disbaled.
• Launch Storage OpROM
Setting old equipment storage ROM open and close, optional for Enalbed, Disbaled.
►
ACPI Settings
Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Advanced
ACPI Settings Enable or Disabe
BIOS ACPI Auto
Configuration.
Enable ACPI Auto Configuration
Enable Hibernation
ACPI Sleep State
[Disabled]
[Enabled]
[S3 (Suspend to RAM)]
→ ←
: Select Scree
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
