J&W JW-H67M-USB3 User Manual

- 24 -
JW-H67M-USB3 User's Manual
• Device power-up delay in second
Optional for Auto
、
Manual, allows setting 1 ~ 40 seconds

Press < ESC> key to return to the Advanced menu
Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Advanced
Pc Health Status
→ ←
: Select Scree
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Sys timperature
CPU timperature
SFAN1 Speed
CFAN1 Speed
CPU VCORE
AVCC
VCC3V
DDR3 VCORE
CPU VCC
PCH VCORE
VSB3V
VBAT
: +23 C
: +39 C
: 2380 RPM
: 1486 RPM
: +1.280 V
: +2.928 V
: +2.912 V
: +1.496 V
: +1.048 V
: +1.040 V
: +3.312 V
: +3.216 V
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
►
System Status Monitor
Teh itim monitor hardware the current working state., including the CPU temperature,
fan speed and kinds of voltage, etc.

Press < ESC> key to return to the Advanced menu
►
Advace Power Manage
Aptio Setup Utility - Copyright (C) 2010 American Megatrends,Inc.
Advanced
Advance Power Manage
→ ←
: Select Scree
↑↓:
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Power on by keyboard
Power on by Mouse
AC Loss Back
[Disabled]
[Disabled]
[Always off]
Version 2.02.1205. (C)Copyright 2010 American Megatrends, Inc.
