J&W X48 Series User Manual

- 4 -
Intel X48 Series User's Manual
1.2 Specications (for JW-X48D2 EXTREME)
CPU
- Supports LGA775 for Intel
®
Core™ 2 Extreme / Quad/ Duo,
Pentium
®
Dual Core, Pentium
®
D, Pentium
®
4, Celeron
®
(Conroe-L)
and next generation 45nm Yorkeld/Wolfdale Processors
Chipset
- Intel
®
X48+Intel
®
ICH9R
- Texas Instruments 1394 controller
- J-Micron eSATA & IDE controller
Main Memory
- Supports 4 x 1.8V DDR2 DIMM sockets supporting up to 8 GB of
system memory
- Supports Dual channel memory architecture
- Support for DDR2 1066/800/667 MHz memory modules
BIOS
- Dual 8Mbit AMI BIOS
,
Supports Plug&Play
- Supports Advanced Power Management ACPI,STR
- Supports 5 x SYS FAN, 1 x CPU FAN
I/O Chipset - iTE IT8718F-S
Integrated Ports
- 1 x PS/2 Keyboard port
- 1 x CMOS_BT switch
- 1 x S/PDIF IN port, 1 x S/PDIF OUT port
- 1 x 1394 Port
- 2 x eSATA ports
- 2 x RJ45 port
- 12 x USB 2.0 ports, USB 1.1 is compliant
- 6 x SATA ports , Maximum Speed to 3GB/s,support for SATA RAID 0,
RAID 1 and RAID 0+1,5
- 1 x IDE connector, 2 x IDE devices could be connected,
Supports ATA 133/100/66/33
- 1 x Floppy Drive, supports 360K/720K/1.2M/1.44M/2.88M oppy disk
Storage
Southbridge
- 6 x SATA 3.0 Gb/s ports
- Intel Matrix Storage Technology supports RAID 0,1,0+1,5
JMicron JMB363 eSATA & IDE Controller
- 2 X External SATA 3.0 Gb/s connector (eSATA)
- Suports RAID 0,1,0+1
- 1 x UltraDMA 133/100/66 for up to 2 PATA devices
Sound
- Supports Realtek
®
ALC 888 codec
- Six audio jacks (Line In / Line Out / MIC In/ Rear Speaker Out /
Center / Subwoofer Speaker Out / Side Speaker Out)
- Supports 8 channel HD Audio,24 bit Audio Codec
- High Denition Audio
- Supports for S/PDIF In/Out (via header)
- Front Panel Jumper, provides stereo MIC port on front panel
Onboard LAN - Dual Marvell® 88E8056 PCIe LAN(10/100/1000 Mbit)
Expansion Slots
- Two PCI Express x16 slots supporting ATI CrossFire™ technology
(The PCI Express x16 slots conform to PCI Express 2.0 standard)
- Three PCI Express x1 slots
- Two PCI slots
- Support PCI Bus interface v2.2 compliant
OS Supports - Microsoft Windows Vista/XP/2000/2003
Form Factor - ATX form factor
:
245mm x 305mm
Remark
1394, Dual Gigabit LAN, Dual BIOS, 100% Solid Capacitors, Debug LED,
eSATA, easy power on/ reset/ clear CMOS switch
