Jandy AquaLink RS series User Manual

Page 22
S1
S2
654321 10987654321 4321
4321
RESET
SERVICE
TIME OUT
FIL
TER PUMP
AUX
1
AUX
2
AUX
3
AUX 4
A
UX 5
AUX 6
AUX 7
RS6 & RS8 ONLY
RS8 ONLY
HEATER
SOLAR
POOL MODE
SPA MODE
SPA DRAIN
SPA FILL
AUTO
To
Solar Sensor
To
Air Sensor
To
Water Sensor
Solar Sensor Part Numbers
7908 - 15’
7932 - 50’
7933 - 125’
“Ears”
Date Code
Water, Air or Solar Sensor
is a 10 K Ohms Thermistor
Part Numbers
7790 - 15’
7786 - 50’
7791 - 125’
Figure 15. Water Temperature Sensor

Jandy AquaLink RS series Specifications

General

Weatherproof	Yes
Automation	Yes
Expandability	Yes
Smartphone Control	Yes
Power Source	120V AC
Communication	RS-485
Humidity Range	0% to 95% non-condensing
Maximum Load Capacity	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Compatible Devices	Jandy pumps, filters, heaters, lights, valves
Wireless Control	Optional (with iAquaLink)
