Jandy AquaLink RS series User Manual

Page 7
Page Up/
OneTouch 1
Back/
OneTouch 2
Page Down/
OneTouch 3
Controller 1
Controller 2
Controller 3
Controller 4
W 2
W 1
W 2
W 1
W 2
W 1
W 2
W 1
Jumper Settings for
Multiple Controllers
Cancel Delay
Button*
Reset
Switch*
Highlight Bar
Moves High-
lighted Bar
Up or Down
Selects
Highlighted
Items
Figure 1. All Button Controller (Front View)
Figure 2. All Button Controller (Back View)
Figure 3. OneTouch Controller (Front View)
Figure 4. OneTouch Controller (Face Plate Removed)
W 2
W 2
W 2
W 2
W 1 W 1
W 1
W 1
Controller 1
Controller 2
Controller 3
Controller 4
Jumper Settings for
Multiple Controllers
Jumpers for
Multiple Controllers
Display Module
Micro Controller
Green Yellow Black Red
*Items Hidden by Cover

Jandy AquaLink RS series Specifications

General

Weatherproof	Yes
Automation	Yes
Expandability	Yes
Smartphone Control	Yes
Power Source	120V AC
Communication	RS-485
Humidity Range	0% to 95% non-condensing
Maximum Load Capacity	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Compatible Devices	Jandy pumps, filters, heaters, lights, valves
Wireless Control	Optional (with iAquaLink)
