12.3 Heat System Spare Parts List and Exploded Parts Diagram
The following JXi Models are equipped with a Cupronickel (CuNi) heat exchanger.
• JXI260NN • JXI400NN • JXI260PN • JXI400PN
12.3.1 Combustion Chamber Assembly
For ASME heater models JXi400NC, JXi400PC, JXi260NC and JXi260PC please go to “Appendix A. ASME
®
Header” on page 55.
Key No Description model 200 model 260 model 260 CuNi model 400 model 400 CuNi
1 Exhaust Elbow Assembly Kit R0590200 R0590200 R0590200 R0590200 R0590200
2 Band Clamp Kit R0590400 R0590400 R0590400 R0590400 R0590400
3 Refractory Kit, Internal R0590500 R0590500 R0590500 R0590500 R0590500
4
Combustion Chamber Shelf
(set of 2: Models 200, 260)
R0590700 R0590700 R0590700 N/A N/A
5 Combustion Chamber Lid Kit R0590800 R0590800 R0590800 R0590800 R0590800
6 Gasket Kit R0590900 R0590900 R0590900 R0590900 R0590900
7 Sight Glass Kit R0305400 R0305400 R0305400 R0305400 R0305400
8 Ignitor Kit R0457502 R0457502 R0457502 R0457502 R0457502
9 Insulation Kit, External R0591000 R0591000 R0591000 R0591000 R0591000
10 Isolator Kit (Thermal) R0593200 R0593200 R0593200 R0593200 R0593200
11 Heat Exchange Assembly R0589402 R0589403 R0746903 R0589405 R0746905
12
Combustion Chamber Assembly
(Includes Header)
N/A R0805803
N/A R0805805 N/A
3
10
1
8
2
5
7
2
6
9
3
260
200
4
6
8
6
7
7
6
7
11
12
12
12
12
12
12
12
12
12
