Page 4
ENGLISH
TruFit Bubbler | Owner’s Manual
Section 2. Installing Jandy
®
TruFit
TM
Bubbler
with Pressure Check Technology
The Bubbler Housing is pre-assembled for easy connection to a water
supply line (1) and a conduit connection for the Jandy HydroCool
Nicheless Pool Light cord to run through.
NOTE: Be sure to read the entire Owner’s Manual completely and
carefully to assure you understand the system before you start
your installation.
NOTE: Do NOT use pipe dope for installation.
NOTE: Install plumbing before any electrical wiring.
2.1 Installation Preparations
The conduit for the low voltage supply cord (12Vac) can be run directly
to a Junction Box where Light(s) connections and Low Voltage wires
from the Transformer (sized correctly) are made. To reduce the risk of
bad connections and unwanted voltage drops, all Power Cords on lights
should run directly to the Low Voltage Transformer.
To ensure maximum safety, only use a transformer that can supply
12VAC and is listed or certied by a Nationally Recognized Testing
Laboratory (NRTL) as compliant with UL 379, Standard for Power
Units for Fountain, Swimming Pool, and Spa Luminaires.
The TruFit Bubbler is designed so that the lens of the tube is
approximately 4”- 8” underwater, but can be deeper as long as the
water supply can be increased.
Keep in mind that the deeper the lens is underwater the less lighting
effect will be above the water. Water flow should be adjusted to the
desired plume while Jandy
®
HydroCool Nicheless Pool Light is
set to the desired color mode. Use the table below to determine the
approximate plume height.
1/2 NOZZLE PLUME HEIGHT
Water Depth 2” 4” 6” 8”
10”
12”
5 GPM 9” 6.5” 4”
10 GPM 22.5” 12” 8” 7” 4.5” 4”
15 GPM 59” 28” 16.5” 10.5” 8” 7.5”
20 GPM 49” 28” 16” 12.5” 11.5”
25 GPM 45.5” 27.5” 18” 16”
