Prophi
®
6R
16
12 PHASE I [ 0°]
[L1] - L1 - N ] Adjustment of current phase position
13 PHASE V [ 0°]
L1 - [L1 - N ] Adjustment of voltage phase position
Phase correction between voltage and current in the measuring system. (refer p.6)
14 C-TEST [YES] ( YES / NO)
The power of the particular capacitor stage is calculated during each switching
operation and compared with the stage output of the capacitor. If the result varies
from the nominal value, an error message is generated. This test can be stopped
here.
15 C-FAULT [40] % (10...75 %)
The deviation from the rated value of the capacitor, for which a fault message is
generated, can be specified here (see point 14)
16 TEST ATTEMPTS [5] ( 1...9)
When at least this number of successive measurements has resulted in a fault in the
capacitor power, a C-fault message is output.
17 OUTPUT 1. STEP [0...255] (0...2550)
The range for entering the stage output can be increased to [0...2550] here, (e.g. for
medium voltage measurement)
18 CONTROL [3] PHASE ( 3 / 1 )
The measuring system of the controller is generally based on single-phase
measurement. For all standard settings (three-phase), the measurement is
converted and all outputs displayed as three-phase values (symmetry in grid
assumed). In the single-phase setting, display and control apply only to the single-
phase value measured (application: single-phase correction in asymmetrical grids)
19 DISPLAY cos
j / tan j
Switched over between cosinus or tangens
j in the display
