Annex 2: Default settings
No.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
27
Parameter
(* as option)
LANGUAGE
I CONVERTER prim.
I CONVERTER sec.
END STOPP
CONTROL SERIES
CONTROL PRINCIPLE
POWER 1. STAGE
TARGET COS-PHI
MEASURING VOLTAGE
V- CONVERTER RATIO
SWITCH- IN TIME
SWITCH- OFF TIME
DISCHARGE TIME
ALARM TEMP.
MESSAGE RELAY *
TEMP. FAN ON
HARMONICS THD-V
Capacitor stages
Password Expert mode 1
Password Expert mode 2
Integration time
Trigger value
Max.simult.switch.power
Operating lock
Switch.operations warning
Fast discharge
Phase shift U/I
C - Test
C - Fail
Test Attempts
Power 1. stage
Control
Default setting
ENGLISH
1000 A
5 A
6
1
INTELLIGENT
25.00 kvar
0.98 IND
230 V L-N
- NO -
40 sec.
40 sec.
60 sec.
55 °C
FAN
30 °C
7,0 %
AUTO
6343
2244
1 sec.
66%
4 x smallest stage
- NO -
50,000
- NO -
0 °
- YES -
40 %
5
0...255 kvar
3 - phase
Programmed values of this
system (to be entered by
manufacturer or operator)
Cannot be changed
Cannot be changed
Note: The following values for the default settings apply only if the controller is supplied
directly from the manufacturer. Otherwise, these values may have been replaced by
settings made by the manufacturer of the compensation network (optimal values for the
relevant network).
