Operating diagram (Brief programming)
Power Factor Controller Prophi-6R
MANUAL MODE SERVICE EXPERT MODE
STOPP C 1.00 IND 1 min./max VOLTAGE
250.0 V
1 PASSWORD ????
[ 6343 ]
1 PASSWORD ????
[ 2244 ]
2 max REACTIVE POWER
88.88 kvar
5 INTEGRATION
TIME: [ 1 ] s
3 max ACTIVE POWER
88.88 kW
4 max APPARENT PWR
88.88 kVA
5 max TEMPERATURE
40.0 °C
6 max THD:
V 2.7 % - I 1.0 %
7 MAXIMUM VALUES
RESET [ NO ]
10 ERROR MEMORY
E [ 1 ] 08H ....
12 TEST RUN
[ NO ]
2 BASIC SETTINGS
NEW ? [ NO ]
EXPERT-MODE 2
3 SWITCH.OPERATION
RESET [ NO ]
2 ALARM RELAY
FAILURE
4 OPERATING TIME
RESET [ NO ]
Activation / Deactivation
of the following
error- messages is
possible with next steps
[ YES/NO ]:
- MEASUR.VOLTAGE
- OVERVOLTAGE
- OVER COMPENSAT.
- UNDERCOMPENSAT.
- HARMONICS !
- OVERTEMPERATURE
- OVERCURRENT
- UNDERVOLTAGE
- SWITCH.OPERATIONs
- MEAS.CURRENT <
C1 : AUTO (FIXED / OFF )
C2 : AUTO (FIXED / OFF )
C3 : AUTO (FIXED / OFF )
C4 : AUTO (FIXED / OFF )
C5 : AUTO (FIXED / OFF )
C6 : AUTO (FIXED / OFF )
8 SWITCHING OPER.
C [ 1 ] - 123
11 ERROR MEMORY
RESET [ NO ]
C - OUTPUT
C1 = 27.3 kvar
9 OPERATION TIME
C [ 1 ] - 12h
6 SWITCH. POWER
max [100] kvar
7 SWITCH. TRIGGER
[ 66 ] %
8 PROGRAM LOCK
[ NO ]
9 SWITCH. OPERATION
WARNING [ 50 ] T.
10 FAST DISCHARGE
[ NO ]
11 DISCHARGE TIME
[ 10 ] s
12 Phase I 0°
[ L1 ] - L1 - N
13 PHASE V 0°
L1 - [ L1 - N ]
14 C - TEST
[ YES ]
3 ALARM-DELAYTIME
[ 10 ] min.
4 UNDERVOLTAGE
[ 50 ] %
5 OVERVOLTAGE
[ 115 ] %
6 FREQUENCY
[ 40...80 Hz ]
15 C - FAILURE
[ 40 ] %
7 SWITCH. OPER. C1
RESET [ NO ]
16
[ 6 ]
TEST ATTEMPT
7 SWITCH. OPER. C6
RESET [ NO ]
17 OUTPUT 1.ST
[ 0...255 kvar ]
8 OPERAT. TIME C1
RESET [ NO ]
8 OPERAT. TIME C6
RESET [ NO ]
18 CONTROL
[ 3-PHASE ]
19 DISPLAY
[ cos
j / tan j ]
Selecting of
capacitors C1-C6
BACK TO 1
BACK TO 1
- 26 -
C1...C6
C1...C6
