Removing or Inserting the Bobbin Case
Open the hook cover.
Raise the needle by turning the handwheel toward you.
Take out the bobbin case by holding the latch.
When inserting the bobbin case, place the horn into the
recess of the hook race.
Hook cover
Latch
Horn
1
2
3
Setting Spool Pins
The spool pins are used for holding the spool of thread in
order to feed thread to the machine.
To use, pull up the spool pin. Push down for storage.
3
2
1
