Jasic MIG250 - Technical Parameters

Page 13
4. Technical parameters
Item
Unit
MIG250
Model
/
MIG250
Input voltage
V
AC
230±15%
Input frequency
Hz
50/60
Rated input current
(AC230V)
A
45.5@MIG
40.0@TIG
45.5@MMA
Rated input power
(AC230V)
kVA
10.5@MIG
9.2@TIG
10.5@MMA
Output voltage range
(MIG)
V
11~30
Wire feed speed range (MIG)
m/min
2~18
Output current range
(MIG)
A
30~250
Output current range
(TIG)
A
5～250
Output current range (MMA)
A
20～220
Arc force range
A
0～100
Hot start current range
A
0 ~ 60
No-load voltage
V
65
VRD voltage
V
11
Rated operating voltage
V
26.5@MIG
20@TIG
28.8@MMA
Efficiency (%)
/
>80%
Duty cycle (%)
/
30%
Power factor
/
0.73@MIG
0.66@TIG
0.72@MMA
Insulation class
/
H
