JasperMIDI guide
Bill Of Materials
There are no rare or expensive components in JasperMIDI. All the items can be obtained from the
usual electronics components suppliers. No special tools are required to build JasperMIDI – just
the usual soldering iron, solder and side cutters. If you wish to program the ATMega328 yourself,
then you will need an AVR compatible ISP programmer like the USBtinyISP.
Resistors
R11, R12, R13
3 220ohm
R2
1 1K
R1, R3, R4, R5, R6,
R7, R8, R9, R10
9 10K
Standard ¼W through hole resistors 1% or 5%
Capacitors
C8
1 15pF Small ceramic capacitor
C6, C7
2 22pF Small ceramic capacitor for crystal
C1, C5, C9
3 0.1uF Small ceramic capacitor – decoupling
C3, C4
2 4.7uF Electrolytic capacitor
All capacitors 2.5mm lead spacing
Diodes
D1
1 1N4001
D3
1 1N4148
D2
1 LED 3mm standard LED (R2 sets brightness)
Integrated circuits etc
IC1 1 ATMEGA328P-P 28 pin DIP – programmed IC supplied with the
PCB
IC2 1 6N137 Opto-isolator 8 Pin DIP
U1
1 MCP1702-5002 5V voltage regulator TO-92
Y1
1 16Mhz Crystal HC49 type low
IC socket
1 8 pin For opto-isolator IC2
IC socket
1 28 pin For IC1
Misc
Pushbutton switch
1 Panel mounted push-button switch, push to close
Mini DIN socket 1 Shielded 8pin Mini DIN socket for Jasper Link connection
5 pin 180° DIN socket 2 Panel mounted socket for MIDI in & out – choose to suit your
enclosure.
JP1
1 2way pin header or use wire to jumper connection
P1, P2, P7
3 2way header MTA-100 or Molex-KK or wire to board
P8
1 3way header MTA-100 or Molex-KK or wire to board
P3
1 ICSP header 2x 3way pin header 2.54mm pitch. Needed if
you wish to update the firmware
P4 1 7way header MTA-100 or MolexKK 7way or 1x3way +
1x4way or wire to board
P5 1 8way header MTA-100 or MolexKK 7way or 2x4way or wire
to board
Hookup wire, mounting hardware, etc.
