Instruction Manual FS140 and FS100 - 6115... / 6116...
© BA_FS140+100_EN_Rev02-2010.doc Page 11 of 20
7 Drives
The following pages feature diagrams of the JAUDT slide valve with a hand crank, an electric motor and an
electropneumatic drive.
The other drive configurations are assembled in the same way as the drive with the hand crank.
Drive with hand wheel or
ratchet
As for drive with hand crank
Drive with sprocket wheel
As for drive with hand crank. The chain must be guided through
both hooks.
8 Accessories
Limit switch inductive
JAUDT 6115... and 6116... slide valves can be fitted with limit switches to report “OPEN - CLOSED”
positions.
The limit switches are preset at the factory. Their setting must be checked during the commissioning
process and adjusted if necessary.
5/2 way solenoid valve (with pneumatic unit)
230 V AC or 24 V DC/48 V AC
The technical data sheets relating to the accessories are appended to this operating manual!
