SECTION 6-ELECTRICAL SYSTEMS JAYCO TOWABLE
12-VOLT FUSE PANEL
The 12-volt fuses are located in the Load Center. They are labeled to indicate fuse sizes,
positions and the components powered. At the beginning of camping season, inspect all the
12-volt fuses in the Load Center and replace as needed.
Replacing a fuse
Before replacing a fuse, always turn off electrical component(s) protected by it.
1. Disconnect the shore power cord.
2. Disconnect the recreation vehicle auxiliary battery main negative battery cable.
3. Remove the fuse panel cover to check fuses.
4. Pull the fuse straight out of the fuse block. If the fuse is not blown, something else
must be causing the problem. Please contact your dealer for further assistance.
5. Insert a new fuse of the same specified voltage, amperage rating and type in the
original location. Never use a higher rated replacement fuse.
The fuse panel label should be kept permanently affixed to your recreation vehicle. The
fuses will not offer complete protection of the recreation vehicle electrical system in the
event of a power surge or spike.
Below is a typical wiring layout. Your individual recreation vehicle may be different.
Refer to the diagram inside the Load Center for specific fuse assignments.
12-VOLT DC OUTLET (IF SO EQUIPPED)
There may be a 12-volt DC outlet (not applicable on all models) in your recreation vehicle.
When the 12-volt DC outlet is used as a power source for an electric appliance, make sure
the appliance operates on 12-volt DC power and that it consumes less than 60 watts (5
amps) of power.
