SECTION 8-PLUMBING SYSTEMS JAYCO TOWABLE
There are two different water systems in your recreation vehicle:
The fresh water system consists of the fresh water holding tank, fresh water
connections, water pump, outside shower assembly (if so equipped), water heater,
faucets, tub/shower, and water purification system (if so equipped).
The waste water system consists of the waste water holding tank, sewage holding
tank, drains and toilet.
PLUMBING SYSTEM MAINTENANCE
Check all fittings, pressure and waste, for leaks before each trip or before vehicle
storage as part of your normal maintenance:
Inspect all faucets, the water purification system (optional) and sink connections
(including drain baskets or filters).
Inspect connections at the water pump and water heater.
At the end of every trip, you should drain any unused water from the fresh water
system.
The fresh water (or potable water) system needs periodic sanitization and
winterization to take care of all the components within the plumbing system and help
discourage the growth of bacteria and other organisms that can contaminate the water
supply.
There are labels affixed to the exterior of the recreation vehicle sidewall that indicate the
locations of the water system drains and fills. Be aware some drain valves may be located
inside the vehicle (once the exterior label is found, go inside to find the drain
corresponding location).
MONITOR PANEL (IF SO EQUIPPED)
The interior wall-mounted Monitor Panel allows you to monitor the fresh water, grey
water, black water and auxiliary battery levels. These functions are controlled using the
"tact" switches located on the monitor panel faceplate. The Monitor Panel operates on 12-
volt DC power supplied by either the converter or auxiliary battery. No power is drawn
from the battery unless a switch is pushed or turned ON. Fuses for the Monitor Panel are
located in the Load Center. Refer to the manufacturer’s operators manual for further
information.
Monitor Panel Monitor Panel
