SECTION 5 - SLIDEOUT SYSTEMS CLASS C MOTOR HOMES
5 - 4
3. The slideout is now free to move. Locate the access panel either at the front
or rear of the slideout rail. Remove the access panel for the manual slideout
shaft.
4. Use a 3/4 socket and ratchet on the hex head located on either end of the
drive shaft and turn the shaft until the slideout is in the position you desire.
When the slideout is fully extended (or retracted), put pressure on the wrench
to ensure a tight seal, then return the brake release lever to its normal
downward position. This will ensure that the slideout is locked into a sealed
position
.
CAUTION
When the slideout motor brake is released, the slideout will not lock into
place, and therefore it will not be sealed from the outdoors! When the slideout
has been retracted, return the brake release lever to its downward position in
order to seal and lock the slideout.
