60
; faults must be cleared for the room to operate normally.
faults can be cleared by pushing and releasing theor buttons
on the wall touchpad.
faults must be cleared by pushing and releasing the SET STOPS/CLEAR
FAULTS button located on the back of the wall touchpad.
Fault
Code
Fault
Type
Fault Codes
Description Possible Cause Possible Solution
1 Major
Stops not
programmed
-Stops have not been
set
-Stops were cleared
-Stops were improperly
set
Steps need to be pro-
grammed by an authorized
service facility.
2 Minor System Fault
-Obstruction present
-Excessive system drag
Run room in opposite direc-
tion. If it continues to move
in the opposite direction,
remove obstruction, exces-
sive weight in room or repair
of damaged component. If
room stops moving in oppo-
site direction, observe fault
code and refer to this chart
4 Major
Excessive
Battery
Voltage
-Bad or loose connec-
tion
-Defective harness
-Open or shorted motor
-Check all connections at
control box and motor.
-Check the harness for bro-
ken wires.
-Put 12.0 VDC direct to the
motor. If it does not run,
replace the motor.
Park brake LED ashing
-Parking brake not set
(if applicable)
-Ground signal lost at
park brake control
-Set parking brake (if ap-
plicable)
-Check for continuity to
ground on wire plugged
into park brake connector at
control box.
6 Minor
Supply voltage to
control box is 17 0 V DC
or greater
Check 2-pin power connector
at control box. If the voltage
is 17. VDC or higher, contact
O.E.M for power and ground
supplies
