Jayco Redhawk 2017 - Overall Process

SE TT ING U P CAM P
U SI N G Y O UR C OA CH
Set T he
B r a k e And
T u r n Off
Eng i ne
E x tend
T he
S li de s
C onne c t
T he
U t ili t i e s
Po si t i on
and
Le v e l
C oa c h
On S i te
C he ck S i te
• Length &
wi dth
• Cl ea r fo r
sli deout s
• N o deb ris
o r
ob s ta cl e s
Overall Pr o cess
T h is is the r e c o mm ended p r o c e ss fo r s ett i ng up c a m p.
Le v e li ng T he C oa c h
N O T ES
• F o r the r ef ri ge r ato r to w o rk p r ope rly and fo r y ou r o w n c o m fo r t, i t
is h i gh ly r e c o mm ended that y ou l e v e l the c oa c h.
• F o r tunate ly , m o s t R V si te s a r e l e v e l and will not r equ ir e an y
ad j u s t m ent. If the c oa c h doe s ha v e to be l e v e l ed, fo ll o w the s e
sim p l e s tep s .
Le v e li ng Wi thout Hy d r au lic J a cks
• P l a c e a S m a r t phone wi th the Bubb l e Le v e l app on the f l oo r i n
s u c h a w a y that i t is ce nt ere d b e t wee n th e fou r w h eels wi th
the l ong si de of the phone pa r a ll e l to the l ength of the c oa c h.
• In th is e x a m p l e the c oa c h is l e v e l si de -
to -si de (x = 0 º ) but need s to ha v e the
r ea r w hee ls r a is ed.
• Us e the c ha r t be l o w to dete rmi ne ho w
m an y i n c he s the r ea r w hee ls need to
be r a is ed to l e v e l the c oa c h.
• N ote: If y ou do not ha v e a S m a r t
phone, y ou c an pu rc ha s e a l e v e l that
i dent i f i e s the nu m be r of deg r ee s
r equ ir ed to l e v e l y ou r c oa c h.
• In th is c a s e w e will u s e the 1.7º sl ope si n c e i t is the cl o s e s t on the
c ha r t. A sl ope of 1.7º r equ ir e s li ft i ng the r ea r w hee ls 0.4 ” pe r foot.
• A ss u mi ng that the d is tan c e bet w een the phone and the r ea r
w hee ls is 6 feet, the r ea r w hee ls need to be r a is ed 2.4 ” ( 6 x 0.4 ) .
50
