E L E C T R ICA L S Y S T E M
Ge n era to r O p era t i on s
You r m oto r ho m e is equ i pped wi th a ga s o li ne po w e r ed gene r ato r .
T he gene r ato r p r odu c e s 30 a m p s of 120 v o l t po w e r and c an
c o m p l ete ly r ep l a c e s ho r e po w e r w hen i t is una v a il ab l e. It is l o c ated
on the d riv e r’s si de f r ont ba y a r ea.
Tr an s fe r S wi t c h
T he gene r ato r i nte r fa c e s wi th the 120 v o l t e l e c t ric a l sys te ms
th r ough a t r an s fe r swi t c h that auto m at ic a lly swi t c he s bet w een
a v a il ab l e s ho r e po w e r and gene r ato r po w e r . T he t r an s fe r swi t c h
doe s not r equ ir e an y m anua l ope r at i on. W hen the gene r ato r is
ope r at i ng, i t po w e rs the c on v e r te r / c ha r ge r w h ic h i n tu r n fun c t i on s
a s a m u l t i-s tage batte ry c ha r ge r to c ha r ge the hou s e batte ry .
N O T E
T he ga s o li ne gene r ato r r equ ir e s 12 -v o l t po w e r f r o m the hou s e
batte ry to s ta r t, and d r a ws fue l to ope r ate f r o m the c ha ssis fue l
tan k . If the fue l l e v e l i n the c ha ssis fue l tan k d r op s ¼ fu ll , the
gene r ato r will auto m at ic a lly s hut off and c annot be r e s ta r ted unt il
the fue l tan k is f ill ed to abo v e ¼ fu ll .
WARN I N G
C a r bon m ono xi de is dead ly . D O N O T r un the gene r ato r w hen y ou r
m oto r ho m e is i ndoo rs o r i n a c onf i ned s pa c e. A s ph yxi at i on o r
c a r bon m ono xi de po is on i ng ha z a r d s e xis t w hene v e r gene r ato r
e x hau s t ga s e s c an a cc u m u l ate.
.
