Jayco Redhawk 2017 - Extending the Slideout Rooms

SE TT ING U P CAM P
U SI N G Y O UR C OA CH
• Befo r e e x tend i ng the sli de s , be c e r ta i n that the sli de s will not
en c ounte r an y ob s ta cl e s s u c h a s t r ee s , h i gh pede s ta ls o r othe r
ob s t r u c t i on s a s the y a r e e x tended.
• T he c ont r o l pane l c onta i n s the swi t c he s to e x tend and dep l o y the
sli de s .
• T he sli de s will not ope r ate wi th the eng i ne r unn i ng, s o be s u r e
that i t ha s been tu r ned off.
• P r e ss and ho l d ea c h r o ck e r swi t c h up to w a r d EX T ( e x tend ) unt il
the sli de is fu lly e x tended. A s s oon as th e sli d e is fu lly
ex t e nd e d , release th e button to av o i d a n y d ama g e to th e
sli d e mec h a n ism.
