117

Use coasters under all glasses, bottles and cans.
Do not store toiletry products directly on your countertop surface. Hair products,
perfumes, colognes, nail products, creams, lotions and potions have a tendency to
spill or leak and go overlooked. Even though the counter top is sealed, a substance
that remains on the surface for an extended period may stain the countertop.
For additional information on the removal of dicult stains or surface damage repair, refer
to the countertop manufacturers user guide.

Soapy water, ammonia based cleaners (not window cleaners as they can leave a waxy build
up that may dull the surface) or commercially available solid surface cleaners will remove
most dirt and residue from all types of nishes. A damp cloth followed by a dry towel will
remove watermarks.
Dicult stains can be removed from the matte nish with a green Scotch Brite® pad and a
mild abrasive cleaner. Disinfect the surface periodically with diluted household bleach (one
part water to one part bleach).
For cuts and scratches, sand the matte nish lightly with (220) ne grit sandpaper until the
cut or scratch is gone. Restore nish with a green Scotch Brite® pad and mild abrasive
cleaner.

Occasionally, clean the solid surface sink by lling one-quarter full with a 50/50 water/
bleach solution. Let soak for 15 minutes, and then wash sides and bottom of sink as solu-
tion drains.
Flooring

Periodically vacuum or sweep to remove dirt and gritty particles. Although most common
spills will not permanently stain the vinyl oors, they are usually easier to remove if wiped
up before they set. Blot with a paper towel and wipe clean with a damp cloth. Do not use
dish detergents or vinegar and water because they will dull your oor.
To care for the vinyl oor covering, use a damp mop with water and a mild cleaner on the
entire oor. DO NOT SOAK THE FLOORING. Use care to avoid wetting the carpet edges.
To avoid problems of “yellowing” linoleum, the ooring manufacturer recommends avoid-
ing cleaners that contain oil based solvents (i.e. lemon oil, Murphy’s Oil Soap, etc.).
Privacy Drape Installation
1. Starting on the drivers side, attach the black plastic hook to the loop on the wall (be-
hind the drivers seat). Make sure the Velcro® on the drape is facing the motor home
windshield.
2. Pull the drape towards the windshield and past the drivers side sun visor. Open the sun
visor against the windshield to hold the drape in place.
3. Continue across the windshield to the passenger side, again opening the sun visor and
placing the drape behind it.
4. Attach the black plastic hook on the passenger side of the drape, to the loop on the wall
behind the passengers seat.
5. Attach the Velcro® at the top edge of the drape to the corresponding Velcro® on the cab
area roof (above the drivers and passenger’s doors).
6. Attach the Velcro® at the bottom corners of the drape to the corresponding Velcro®
on the wall.


