At the beginning of the camping season, inspect the circuit breakers and replace as needed.
Test by turning each circuit breaker “o” and back “on”. Circuit breakers are wearable parts
and must be replaced as needed as part of your RV maintenance. If you have any questions,
contact your dealer.
A label is provided to explain the function of every 120-volt circuit breaker. This label is
located on or near the appropriate load center or sub-panel and must remain permanently
axed to the recreation vehicle.
Replacement circuit breakers must be of the same voltage, amperage rating
and type. Never use a higher rated replacement circuit breaker; doing so may
cause a re by overheating the RV wiring.
Approximate Electrical Load Ratings
12 VOLT SYSTEM
Exterior Entertainment Center 5-7 AMPS
Fan 1.5 AMPS
Furnace 12.0 AMPS
Generator Start 95.0 AMPS*
Illuminated Switch .125 AMP
Inverter variable
Leveling System 95.0 AMPS*
LP Detector .125 AMP
Light; LED 1.7 AMPS
Light; Vanity 4.2 AMPS
Lights; Aisle 1.0 AMP
Lights; Baggage Compartment / Shower 1.4 AMPS
Lights; Decorative Wall / Map / Porch 1.5 AMPS
Lights; Double -12” 2.0 AMPS
Lights; Double -18” 2.5 AMPS
Power Awning 10.0 AMPS*
Power Vent 5.0 AMPS
Refrigerator 3.0 AMPS
Step Cover 10.0 AMPS*
TV Plate/Antenna Booster 1.0 AMP
Water Heater 6.0 AMPS
Water Pump 7.0 AMPS
*Momentary Load
12 Volts: Labeled watts divided by 12 = Power consumed in AMPS
