Jaytech 600N - Photo beam setting; Auto-close setting

- 9 -
NOTE – Later model openers
may have ‘S’ in place of ‘SET’,
‘C’ in place of ‘CODE’, ‘+’ in
Place of ‘UP’ and ‘-‘ in place of
‘DOWN’
4．Photo beam setting
1. Auto-close setting
Press and hold “SET” button for 3 seconds until the LED
flashes “1”. Press “UP” or “DOWN” to increase or
decrease, adjust the LED to flash ”4”, then press “SET”
button to enter into auto-close setting, the LED displays
the current setting.
Press “UP” or “DOWN” button to adjust the auto-close
time. Press “UP” button once, the auto-close time will
increase 1 minute, the maximum time is 9 minutes.
Press “DOWN” button once, the auto-close time
decreases by 1 minute. The auto-close function will be
turned off when the LED displays “0”. Press “SET”
button to confirm, the opener returns to standby mode.
The auto-close function is only be available when the
door is fully open and the photo beam function is on.
The default setting is “o”
Press and hold “SET” button for 3 seconds until the
LED flashes “1”. Press “UP” button until the
LED flashes “3”, press “SET” button. The display is now
in photo beam setting mode. The LED displays the
current setting.
Press “UP” button, the LED displays “1”, the Photo
beam Function is enabled. Press “DOWN” button, the
LED displays “0” to cancel this function. Press “SET”
button to confirm. The opener returns to standby mode.
The default setting of photo beam is “0”.
Notice: Default setting must be used when no photo
beams are installed.
