Connection outside Europe:
The P7 may only be connected to mains supply systems according to this table:
mains
P7
2 conductor
1 phase
L
N
L
N
PE
3 conductor
1 phase
L
N
L
L
PE
N
4 conductor
3 phases
L
1
L
2
L
3
N
L
N
PE
WARNING: P7 only can be used
in Canadian mains supply sys-
tem with 2 conductor, 1 phase
with maximum 120V!
!
Connected load: Voltage 100-240 Volts, frequency 50 - 60 Hz, power max. 380 VA.
Connect the xture to a proper installed grounded system only. If any doubts on the electrical
installations occur, consult a qualied electrician. In case of damages occurring due to a not
proper installed electrical system, warranty claims will be invalidated. Don´t use xtures when
top cover is not xed properly. Contact with electronic parts can result in risk for life. (Electrical
shock 100-240 V)
Connect xture only after assuring that the electrical installation ts your demands. If any doubts
occur consult a qualied technician!
4.2 Connection to mains
WARNING: P7 might light up immediately if standalone mode is active or DMX signal
is connected!
!
Power can be relayed to another device via the grey PowerCon throughput socket that accepts
a grey PowerCon NAC3FCB cable connector. Note that blue input and grey throughput connec-
tors have different design: one type cannot be connected to the other. The value of P7 in chain
depends on the local power network. Never use more than nine (if you have 230V/16A) in one
line. Power throughput cable must be rated 20A minimum, have three conductors 1,5mm² min-
imum conductor size and a outer cable diameter of 5-15mm. Use only original PowerCon plug
from Neutrik. See installation manual from manufacturer (www.neutrik.com).
4.3 Relaying power to other fixtures
WARNING: To ensure proper installation of the plug consult a qualied technician!
!
Color Function Symbol
brown live „L“
blue neutral „N“
green/yellow ground „PE“
