6. DMX protocol
The P7 offers 3 different channel modes. In the menu area PERSONALITY -> DMX MODE you
can select your mode. The used mode will be displayed in the main menu.
Mode 1 (M1) Mode 2 (M2) Mode 3 (M3)
Channel 1 Pan Pan Pan
Channel 2 Pan ne (16 Bit) Pan ne (16 Bit) Pan ne (16 Bit)
Channel 3 Tilt Tilt Tilt
Channel 4 Tilt ne (16 Bit) Tilt ne (16 Bit) Tilt ne (16 Bit)
Channel 5 Control Control Control
Channel 6 Shutter Shutter Shutter
Channel 7 Dimmer Dimmer Dimmer
Channel 8 Focus Focus Focus
Channel 9 Zoom Zoom Zoom
Channel 10 Iris Iris Iris
Channel 11 Gobo 1 Gobo 1 Gobo 1
Channel 12 Gobo 2 Gobo 2 Gobo 2
Channel 13 Gobo 2 rotation Gobo 2 rotation Gobo 2 rotation
Channel 14 Color wheel Gobo 2 rot. ne 16Bit Color wheel
Channel 15 Cyan Color wheel Cyan
Channel 16 Magenta Cyan Magenta
Channel 17 Yellow Cyan ne (16 Bit) Yellow
Channel 18 Sparkle Magenta Sparkle
Channel 19 Sparkle speed Magenta ne (16 Bit) Sparkle speed
Channel 20 Prism Yellow Prism
Channel 21 Prism rotation Yellow ne (16 Bit) Prism rotation
Channel 22 Frost Sparkle Frost
Channel 23 Macro Sparkle speed Macro
Channel 24 Pan/Tilt speed Prism Blackout move
Channel 25 Effect speed Prism rotation
Channel 26 Blackout move Prism rotation ne (16 Bit)
Channel 27 Frost
Channel 28 Macro
Channel 29 Pan/Tilt speed
Channel 30 Effect speed
Channel 31 Blackout move
6.1 Operating modes
