JB-Lighting P7 - DMX Channel Functions

P7
- 42 -
M1 M2 M3 Function DMX
1 1 1 Pan (X) movement 433° 000-255
2 2 2 Pan (X) ne (16 Bit) 000-255
3 3 3 Tilt (Y) movement 280° 000-255
4 4 4 Tilt (Y) ne (16 Bit) 000-255
5 5 5 Control
Dimmer fade out with Fader - slow -> fast (reaction time of lighting desk fast)
Dimmer fade out with Fader - slow -> fast
Dimmer fade out with Fader - slow -> fast
Dimmer fade out with Fader - slow -> fast
Dimmer fade out with Fader - slow -> fast (reaction time of lighting desk slow)
Camera mode, 50Hz (after 2 seconds)
Camera mode, 60Hz (after 2 seconds)
Camera mode, FLEX (after 2 seconds)
Safe
Reset (after 2 seconds)
Safe
000-007
032-039
064-071
096-103
128-135
208-215
216-223
224-231
232-239
240-247
248-255
6 6 6 Shutter
Shutter closed
Shutter open
Shutter pulse opening >20Hz (fast to slow)
Shutter open
Fade effect with dimmer (dimmer effect slow - dimmer effect fast)
Shutter open
Shutter closed
Shutter pulse opening <20Hz (fast to slow)
Shutter open
Shutter pulse closing (fast to slow)
Shutter closed
Shutter fade, 0% (fast to slow)
Shutter open
Shutter fade, 100% (fast to slow)
Shutter closed
Shutter random 100% (fast to slow)
Shutter open
Shutter random 0% (fast to slow)
Shutter closed
Shutter random fade 0% (fast to slow)
Shutter open
Shutter random fade 100% (fast to slow)
Shutter open
000-015
016-095
096-110
111-111
112-125
126-126
127-127
128-142
143-143
144-158
159-159
160-174
175-175
176-190
191-191
192-206
207-207
208-222
223-223
224-238
239-239
240-254
255-255
7 7 7 Dimmer 0 - 100% 000-255
8 8 8 Focus 0-100% 000-255
9 9 9 Zoom 48° (0%) - 8° (100%) 000-255
6.2 DMX channel functions
