JB Pipepuller 1700 - Parts Description

JB Pipepuller l Parts Description
9
10’ Tall
8’ Tall
6’ Tall
4’ Tall
Upper Shoe
Inner Post
Strut Extensions
Standard Strut
Selector Valve
Power Unit
Pull Cylinder
Key Link
Short Link
J-Hook
Medium J-Link
Long J-Link
Lower Shoe
Battery
Strut Cylinder
Lift Here
Medium J-Link
PARTS DESCRIPTION
Short Post
Selector Valve
Power Unit
Pull Cylinder
Pull Clevis
J-Hook
Lower Shoe
Battery
Lift Here
Outer Post Strut
Remote Receiver
Bushings
Front Mount Tube
Front Mount
Stabilizer
JB Pipepuller with Front Mount Tube
(Used on Culverts 4’ Tall and Shorter)
JB Pipepuller Base Unit
(Used on Reinforced Concrete Culverts 4’-10’ Tall)
n
Always bolt heavy duty strut
extentions first to lower strut.
n
ALL Strut Extensions must be
bolted on with grade 8 bolts,
nuts and lock washers.
Torque at 100 ft. lbs.
